Cat6A UTP 180° Toolless Keystone Jack

FEATURES

Cat6A / Class EA transmission target
1–500 MHz performance range
UTP / Unshielded RJ45 8P8C interface
Toolless termination
T568A / T568B wiring identification
Compact unshielded modular format

Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote

0 People watching this product now!

chat with sales

Choosing the Cat6A UTP 180° Toolless Keystone Jack

Cat6A performance (500 MHz) supports 10 Gb Ethernet to 100 m when used with Cat6A cable. The unshielded body is for U/UTP cable in standard office installations. The 180° straight-through entry suits patch panels and deep back boxes. Toolless termination lets installers terminate without a punch tool, saving time on large projects.

Order code: TMT-06ABP1 .. Send us the quantity for a project quotation and datasheet.

TMT Cat6A UTP 180° Toolless Keystone Jack Series

The TMT Global Cat6A UTP 180° Toolless Keystone Jack is a controlled keystone connectivity product for Cat6A / Class EA structured cabling terminations. It provides a standards-aligned RJ45 8P8C interface with toolless termination, 180° straight geometry and utp / unshielded construction. The product is intended for professional network installations where repeatable termination, reliable contact performance and consistent TMT specification control are required.

FEATURES

Cat6A / Class EA transmission target
1–500 MHz performance range
UTP / Unshielded RJ45 8P8C interface
Toolless termination
T568A / T568B wiring identification
Compact unshielded modular format

APPLICATIONS

Work-area outlets
Patch panels
Enterprise LAN
IP CCTV / VoIP
Commercial buildings

Technical Specification

Parameter	TMT Declared Specification
Product type	Cat6A UTP 180° Toolless Keystone Jack
SKU	TMT-06ABP1
Category / class	Cat6A / Class EA
Frequency range	1–500 MHz
Connector interface	RJ45, 8P8C
Shielding	UTP / Unshielded
Orientation	180° straight
Termination	Toolless
Housing / body	High-impact flame-retardant polycarbonate, UL 94 V-0
Contact material	Phosphor bronze
Contact plating	50 µin gold over nickel at mating area
IDC / termination contact	Phosphor bronze, tin plated
Conductor compatibility	22–26 AWG solid copper
Wiring scheme	T568A / T568B colour-coded identification
Contact resistance	≤ 20 mΩ initial
Insulation resistance	≥ 500 MΩ @ 100 V DC
Dielectric withstand	≥ 1,000 V DC / 1 min
Mating durability	≥ 750 plug insertion cycles
Operating range	-10 °C to +60 °C
Packaging	Individual bag or box; master carton per approved TMT packing

STANDARDS & COMPLIANCE

IEC 60603-7-41:2010
ISO/IEC 11801-1 structured cabling system application
ANSI/TIA-568.2-D where applicable
EN 50173 where applicable
UL 94 V-0 polymer components
RoHS
REACH

AUTHORITY FIRE-PERFORMANCE NOTE

Keystone jacks are connectivity hardware, not permanent telecom cables. Euroclass/CPR cable fire-rating and IEC/EN 60332-1-2 cable flame tests are not applied to this hardware unless a specific accredited assembly test covers the product. Use UL 94 V-0 for applicable plastic parts.

PRODUCT CONTROL STATEMENT

This SKU is defined by the published TMT website/datasheet specification. Any OEM production must match the listed construction, interface, category, termination and compliance requirements and provide supporting test/conformity evidence.
