1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable
KEY FEATURES
- 1 Pair (2 Core) controlled twisted-pair construction
- Overall foil + tinned-copper braid + drain wire
- 150 Ω nominal protocol-design target
- 22 AWG Series option
- PVC, LSZH and outdoor PE jacket choices
- Exact searchable ordering code for every standard combination
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
TMT 1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable Series
TMT Global 1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable is a controlled protocol-bus cable family for profibus dp / fms fixed bus segments and related industrial or building-automation networks. The product page fixes the 1 pair (2 core), foil + braid shielded and 150 Ω nominal electrical family, while the TMT Series ordering table provides exact jacket and conductor-size item codes for customer search, quotation and project selection.
KEY FEATURES
- 1 Pair (2 Core) controlled twisted-pair construction
- Overall foil + tinned-copper braid + drain wire
- 150 Ω nominal protocol-design target
- 22 AWG Series option
- PVC, LSZH and outdoor PE jacket choices
- Exact searchable ordering code for every standard combination
TYPICAL APPLICATIONS
- PROFIBUS DP / FMS fixed bus segments
- PLC, remote-I/O, drive and field-device networks
- Factory automation and machine control
- Permanent indoor and project outdoor installations
- The 22 AWG code represents the approximately 0.64 mm PROFIBUS conductor format; protocol testing remains mandatory.
Technical Specification
| PARAMETER | SPECIFICATION |
| Protocol family | PROFIBUS DP |
| Pair / core configuration | 1 Pair (2 Core) |
| Conductor material | Bare copper |
| Conductor construction | Solid or stranded bare-copper conductor |
| Available conductor sizes | 22 AWG |
| Pair insulation | PE / foam-skin PE, Series dependent |
| Shielding | Overall foil + tinned-copper braid + drain wire |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Violet indoor; Black outdoor |
| Characteristic impedance | 150 Ω nominal |
| Series code | 02B-PD |
| Ordering variants | Conductor size × jacket, as listed on Page C |
| Package length | 305 m standard package |
AWG / NOMINAL AREA / SERIES AVAILABILITY
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m |
| AWG | 22 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Violet |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable | 02B-PD | 22 awg | PVC | Violet | 305 m |  | |
| 1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable | 02B-PD | 22 awg | LSZH | Violet | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded PROFIBUS DP Bus Cable | 02B-PD | 22 awg | PE Outdoor | Black | 305 m | |
