3 Core Standard Fire-Resistant Voice Alarm Cable

KEY FEATURES

3 copper conductors with fire-resistant insulation system
Overall foil screen and drain wire
Low-smoke zero-halogen outer jacket
Red, orange and white project colour options
Standard fire-resistance target subject to evidence

Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote

0 People watching this product now!

chat with sales

Choosing the 3 Core Standard Fire-Resistant Voice Alarm Cable

Three cores carry 1 speaker lines or a speaker line plus control in one run.

Order code: 03C-S-VS. Send us the length, jacket and quantity for a project quotation and datasheet.

TMT Global 3 Core Standard Fire-Resistant Voice Alarm Cable Series

TMT Global 3 Core Standard Fire-Resistant Voice Alarm Cable is a controlled screened LSZH family intended for voice-alarm, emergency communication and related life-safety circuits where a standard fire-resistance classification is specified. The final published fire-resistance claim must match the exact TMT construction, accredited test evidence and project authority requirement.

KEY FEATURES

3 copper conductors with fire-resistant insulation system
Overall foil screen and drain wire
Low-smoke zero-halogen outer jacket
Red, orange and white project colour options
Standard fire-resistance target subject to evidence

TYPICAL APPLICATIONS

Voice-alarm circuits
Emergency voice communication
Public-address evacuation systems
Fire-safety control circuits
Critical building communication

Technical Specification

PARAMETER	SPECIFICATION
Product type	Fire-resistant screened voice-alarm / emergency communication cable
Geometry / configuration	3 core
Conductor material	Bare copper
Conductor construction	Stranded copper conductors
Available conductor sizes	14 AWG / 16 AWG / 18 AWG
Fire-resistance family	Standard fire-resistant construction family; exact tested classification supplied with approved product documentation
Core / pair construction	3 core; colour-coded insulated conductors with fire-resistant insulation system
Screening	Overall foil screen
Drain wire	Drain wire included
Outer-jacket options	Fire-resistant LSZH
Cable form	Round
Standard colours	Red / Orange / White
Package length	305 m standard package
Typical applications	Voice-alarm, emergency communication and public-address evacuation circuits

AWG / NOMINAL AREA / SERIES AVAILABILITY

AWG	NOMINAL AREA	SERIES AVAILABILITY
14 AWG	2.08 mm²	Fire-resistant LSZH • Red / Orange / White • 305 m
16 AWG	1.31 mm²	Fire-resistant LSZH • Red / Orange / White • 305 m
18 AWG	0.823 mm²	Fire-resistant LSZH • Red / Orange / White • 305 m
