1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable
KEY FEATURES
- 1 Pair (2 Core) controlled twisted-pair construction
- Overall aluminium/polyester foil plus tinned-copper braid and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
0
People watching this product now!
chat with sales
Description
TMT 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable Series
TMT Global 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable is a configurable instrumentation-cable family for analogue, digital and process-control signals between field instruments, control panels, PLC/DCS systems and monitoring equipment. The product page fixes the 1 pair (2 core) foil + braid shielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.
KEY FEATURES
- 1 Pair (2 Core) controlled twisted-pair construction
- Overall aluminium/polyester foil plus tinned-copper braid and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
TYPICAL APPLICATIONS
- 4–20 mA and 0–10 V instrumentation loops
- Process measurement, transmitters and monitoring circuits
- PLC/DCS analogue and digital I/O wiring
- RTD, valve, actuator and positioner circuits
- Industrial plants, utilities and building-services systems
Technical Specification
| PARAMETER | SPECIFICATION |
| Product type | Instrumentation and process-control cable |
| Element configuration | 1 pair / 2 insulated cores |
| Conductor material | Bare copper |
| Conductor construction | Solid or stranded construction |
| Available conductor sizes | 14 / 16 / 18 / 20 / 22 / 24 AWG |
| Element formation | Two insulated conductors twisted as each pair |
| Core insulation | PVC / PE / halogen-free compound options, construction dependent |
| Screening | Overall aluminium/polyester foil plus tinned-copper braid and drain wire |
| Outer-jacket options | PVC / LSZH / PE Outdoor |
| Cable form | Round |
| Standard colours | Grey for PVC/LSZH; black for PE Outdoor |
| Package length | 305 m standard TMT package |
| Ordering basis | AWG and jacket define the exact searchable Series SKU |
| Series records | 18 searchable Series SKUs per family |
AWG / NOMINAL AREA MATRIX
| AWG | NOMINAL AREA | SERIES AVAILABILITY |
| 14 AWG | 2.08 mm² | PVC / LSZH / PE Outdoor • 305 m • Project option |
| 16 AWG | 1.31 mm² | PVC / LSZH / PE Outdoor • 305 m • Standard / project |
| 18 AWG | 0.823 mm² | PVC / LSZH / PE Outdoor • 305 m • Main market |
| 20 AWG | 0.518 mm² | PVC / LSZH / PE Outdoor • 305 m • Main market |
| 22 AWG | 0.326 mm² | PVC / LSZH / PE Outdoor • 305 m • Main market |
| 24 AWG | 0.205 mm² | PVC / LSZH / PE Outdoor • 305 m • Standard / project |
Additional information
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 23 awg, 24 awg |
|---|---|
| Brand | TMT Global |
| Colour | Black, Grey |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
Download Spec.
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 14 awg | PVC | Grey | 305 m |  | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 14 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 14 awg | PE Outdoor | Black | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 16 awg | PVC | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 16 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 16 awg | PE Outdoor | Black | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 18 awg | PVC | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 18 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 18 awg | PE Outdoor | Black | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 20 awg | PVC | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 20 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 20 awg | PE Outdoor | Black | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 22 awg | PVC | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 22 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 22 awg | PE Outdoor | Black | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 24 awg | PVC | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 24 awg | LSZH | Grey | 305 m | | |
| 1 Pair (2 Core) Foil + Braid Shielded Instrumentation Cable | P01B-MC | 24 awg | PE Outdoor | Black | 305 m | |
