2 Pairs (4 Core) Unshielded Instrumentation Cable
KEY FEATURES
- 2 Pairs (4 Core) controlled twisted-pair construction
- No metallic screen; use only where EMC and crosstalk conditions permit
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
Full specifications & datasheet: tmtglobal.co.uk →
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
Choosing the 2 Pairs (4 Core) Unshielded Instrumentation Cable
Two pairs serve one or two 4–20 mA loops, the typical run from a single transmitter to its junction box. No metallic screen keeps it light, flexible and quick to terminate; choose it for clean electrical environments where the route stays away from mains power and motor drives.
Related options in this range: 1 Pair (2 Core) Unshielded Instrumentation Cable · 1 Triad (3 Core) Unshielded Instrumentation Cable · 2 Triads (6 Core) Unshielded Instrumentation Cable · 4 Pairs (8 Core) Unshielded Instrumentation Cable · 2 Pairs (4 Core) Foil + Braid Shielded Instrumentation Cable · 2 Pairs (4 Core) Foil Shielded Instrumentation Cable
Order code: P02U-MC. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT 2 Pairs (4 Core) Unshielded Instrumentation Cable Series
TMT Global 2 Pairs (4 Core) Unshielded Instrumentation Cable is a configurable instrumentation-cable family for analogue, digital and process-control signals between field instruments, control panels, PLC/DCS systems and monitoring equipment. The product page fixes the 2 pairs (4 core) unshielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.
KEY FEATURES
- 2 Pairs (4 Core) controlled twisted-pair construction
- No metallic screen; use only where EMC and crosstalk conditions permit
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
TYPICAL APPLICATIONS
- 4–20 mA and 0–10 V instrumentation loops
- Process measurement, transmitters and monitoring circuits
- PLC/DCS analogue and digital I/O wiring
- RTD, valve, actuator and positioner circuits
- Industrial plants, utilities and building-services systems
Technical Specification
AWG / NOMINAL AREA MATRIX
| Brand | TMT Global |
|---|---|
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 24 awg |
| Colour | Black, Grey |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
