Cat6A STP 24-Port Angled Patch Panel | Loaded
FEATURES
- Loaded shielded angled Cat6A panel
- Class EA target to 500 MHz
- 360° shield continuity
- Side routing to vertical managers
- Grounding point
- Rear cable support
Full specifications & datasheet: tmtglobal.co.uk →
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
TMT Global Cat6A STP 24-Port Angled Patch Panel | Loaded Series
Cat6A STP 24-Port Angled Patch Panel | Loaded is a TMT Global copper patch-panel product for loaded shielded Cat6A 10G patching with angled cable presentation. It is designed for professional structured cabling installations where consistent rack organization, reliable cable support and standards-aligned connectivity are required. The product shall be supplied according to the declared TMT specification and applicable standards listed in the technical datasheet.
FEATURES
- Loaded shielded angled Cat6A panel
- Class EA target to 500 MHz
- 360° shield continuity
- Side routing to vertical managers
- Grounding point
- Rear cable support
APPLICATIONS
- 10G shielded data centres
- Industrial LAN
- High-EMI racks
- Security/control systems
- Transport networks
STANDARDS & COMPLIANCE
- ISO/IEC 11801-1 system application
- Class EA / 10GBASE-T application target
- Grounding/earthing continuity for shielded systems
- ANSI/TIA-568.2-D system application
- EN 50173 system application
- IEC 60297-3-100 for 19-inch rack interface
- UL 94 V-0 polymer parts
- RoHS
- REACH
Technical Specification
| Brand | TMT Global |
|---|
