Cat6 UTP 24-Port Patch Panel | Unloaded
FEATURES
- 24-port unloaded modular format
- Standard 19-inch 1U rack mounting
- SPCC galvanized steel construction
- Rear cable support and labelling field
- Accepts TMT Cat6 UTP keystone modules
- Black powder-coated finish
Full specifications & datasheet: tmtglobal.co.uk →
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
TMT Global Cat6 UTP 24-Port Patch Panel | Unloaded Series
Cat6 UTP 24-Port Patch Panel | Unloaded is a TMT Global copper patch-panel product for standard 19-inch telecom rooms and cabinets. It is designed for professional structured cabling installations where consistent rack organization, reliable cable support and standards-aligned connectivity are required. The product shall be supplied according to the declared TMT specification and applicable standards listed in the technical datasheet.
FEATURES
- 24-port unloaded modular format
- Standard 19-inch 1U rack mounting
- SPCC galvanized steel construction
- Rear cable support and labelling field
- Accepts TMT Cat6 UTP keystone modules
- Black powder-coated finish
APPLICATIONS
- Structured cabling
- Data centres
- Comms rooms / IDF-MDF
- Enterprise LAN
- CCTV & IP networks
STANDARDS & COMPLIANCE
- ISO/IEC 11801-1 system application
- ANSI/TIA-568.2-D system application
- EN 50173 system application
- IEC 60297-3-100 for 19-inch rack interface
- UL 94 V-0 polymer parts
- RoHS
- REACH
Technical specification
| Brand | TMT Global |
|---|
