cat6 23awg 4 twisted pair U-UTP data Cable tmt 305m

Rated 5.00 out of 5 based on 1 customer rating

د.إ260.00

Standards: ANSI/TIA/568.2-D CENELEC EN 50288-5IEC 61156-5 (ISO/IEC-11801 Class -E)

General Specification:

• Conductor: Bare Copper
• Conductor Size: 23AWG
• No. Of Pairs: 4 twisted pairs
• Overall Coverage: Plastic Tape
• Outer Jacket: PE
• Jacket Color: Blue/Black/Grey/Violet/Orange
• Packing: 305m / Box
• Model No: TMT-4025
• Item Code: 6X132BOK

0 People watching this product now!

TMT GLOBAL cat6 23awg 4 twisted pair U-UTP data Cable 305m

The TMT GLOBAL cat6 23awg 4 twisted pair U-UTP data Cable tmt (305m) offers robust performance for high-speed networking applications. Designed to support data transmission speeds of up to 1 Gbps, this cable is ideal for both residential and commercial use. Its 23AWG construction enhances durability while minimizing signal loss, ensuring reliable connectivity over long distances.

One of the notable features is its U/UTP design, which reduces electromagnetic interference, making it suitable for environments with multiple electronic devices. The 305-meter length provides ample cable for extensive network setups, reducing the need for additional purchases.

However, potential limitations include its lack of shielding, which may expose the cable to interference in particularly noisy environments. Additionally, installation may require careful planning to prevent physical damage to the cable during setup. Overall, the TMT GLOBAL Cat6 cable stands out for its performance and length, making it a solid choice for a variety of networking needs.

APPLICATION

10BASE-T, 100BASE-TX Fast Ethernet,
1000BASE-T (IEEE802.3
100VG-AnyLAN (IEEE802.12)
550 MHz Broadband Video
Voice, T1, ISDN
155/ 622 Mbps ATM
Power over Ethernet (POE)
GENERAL SPECIFICATION
4 Pairs UnShielded Twisted Pair (UTP) Cable
Gold Plated: 30U”
Color Code: Aqua/Black/Blue/green/Grey/Orange/Red/Violet/White/Yellow r custom color
Length : 0.12/0.15/0.50/1/2/3/5/8/10/15/20/25/30/40/50/70/100/meter r custom Length
Contact blade: Phosphor Bronze
Insulation Material: HD-PE-PVC-LSZH
Jacket Material: PVC UL94V-0

PHYSICAL AND MECHANICAL PROPERTIES
Conductor Resistance: ≤5Ω – ≤20Ω
Insulation Resistance: ≥10MΩ
Characteristic Impedance: 100 ― 6 Ohm @ 1-250MHz -1-500 MHz
Contact Resistance: 20 m Ohm max
Resistance Unbalance: 2% max
Dielectric strength: 1000 volts/1 minute min rms
Cable to Plug Tensile Strength: 9 Kgf (90N) min
Durability: 750
Temperature Operating Range: -25°C to 70°C
Country Of Origin: Made in UAE
By Fahad Cables Industry FZE
