6 Triads (18 Core) Foil Shielded Instrumentation Cable
KEY FEATURES
- 6 Triads (18 Core) controlled twisted-triad construction
- Individually foil-screened pairs/triads plus overall foil screen and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
Full specifications & datasheet: tmtglobal.co.uk →
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
Choosing the 6 Triads (18 Core) Foil Shielded Instrumentation Cable
With six individually screened triads, one run can carry six three-wire field signals such as RTD temperature sensors or three-wire transmitters back to the control system. An overall aluminium/polyester foil screen with drain wire blocks high-frequency interference, so it suits signal and data circuits that share containment with other cabling.
Related options in this range: 3 Triads (9 Core) Foil Shielded Instrumentation Cable · 4 Triads (12 Core) Foil Shielded Instrumentation Cable · 12 Pairs (24 Core) Foil Shielded Instrumentation Cable · 16 Pairs (32 Core) Foil Shielded Instrumentation Cable · 6 Triads (18 Core) Foil + Braid Shielded Instrumentation Cable · 6 Triads (18 Core) Unshielded Instrumentation Cable
Order code: T06S-MC. Send us the length, jacket and quantity for a project quotation and datasheet.
TMT 6 Triads (18 Core) Foil Shielded Instrumentation Cable Series
TMT Global 6 Triads (18 Core) Foil Shielded Instrumentation Cable is a configurable instrumentation-cable family for analogue, digital and process-control signals between field instruments, control panels, PLC/DCS systems and monitoring equipment. The product page fixes the 6 triads (18 core) foil shielded construction, while the TMT Series ordering table provides exact AWG and jacket-specific item codes for customer search, quotation and project selection.
KEY FEATURES
- 6 Triads (18 Core) controlled twisted-triad construction
- Individually foil-screened pairs/triads plus overall foil screen and drain wire
- 14, 16, 18, 20, 22 and 24 AWG Series options
- PVC, LSZH and outdoor PE jacket choices
- Bare-copper conductor; solid or stranded by released drawing
- Exact searchable ordering code for every standard combination
TYPICAL APPLICATIONS
- 4–20 mA and 0–10 V instrumentation loops
- Process measurement, transmitters and monitoring circuits
- PLC/DCS analogue and digital I/O wiring
- RTD, valve, actuator and positioner circuits
- Industrial plants, utilities and building-services systems
Technical Specification
AWG / NOMINAL AREA MATRIX
| Brand | TMT Global |
|---|---|
| Colour | Black, Grey |
| Jacket Type | PVC, LSZH, PE Outdoor |
| Length | 305 m |
| AWG | 14 awg, 16 awg, 18 awg, 20 awg, 22 awg, 24 awg |
