1 Pair / 2 Core Standard Fire Telephone / EVC Cable
KEY FEATURES
- Twisted-pair / two-conductor fire-life construction
- Overall screened LSZH family baseline
- Standard fire-survival architecture — certification evidence required before claim
- Red / White controlled Series rows
- 305 m standard TMT package
Supplied in the UAE by TMT Global UAE from our Sharjah warehouse (Industrial Area 18) and Dubai office (Naif), for projects in Dubai, Sharjah, Abu Dhabi and across the Emirates. Request a quote
0
People watching this product now!
chat with sales
Description
TMT 1 Pair / 2 Core Standard Fire Telephone / EVC Cable Series
Screened fire-resistant pair cable family for emergency voice communication and firefighter telephone circuits where a system-approved two-way voice pair is required.
KEY FEATURES
- Twisted-pair / two-conductor fire-life construction
- Overall screened LSZH family baseline
- Standard fire-survival architecture — certification evidence required before claim
- Red / White controlled Series rows
- 305 m standard TMT package
TYPICAL APPLICATIONS
- Firefighter telephone circuits
- Emergency voice communication outstations
- Refuge communication points
- Fire-control-room voice links
- Two-way fire emergency communication
Technical Specification
| TECHNICAL SPECIFICATION | VALUE |
| Product family | 1 Pair / 2 Core Standard Fire Telephone / EVC Cable |
| Series | 01P-S-TS |
| Primary application | Emergency voice communication / firefighter telephone circuits |
| Core / geometry | 1 twisted pair / 2 conductors |
| Conductor material | Bare copper |
| Conductor sizes | 18 AWG / 16 AWG / 14 AWG |
| Screening | Overall foil screen + drain / circuit protective conductor arrangement |
| Outer sheath | LSZH |
| Sheath colours | Red / White |
| Fire-survival level | Standard |
| Standard package | 305 m |
CONDUCTOR SIZE (AWG) / SERIES AVAILABILITY
| CONDUCTOR SIZE (AWG) | SERIES AVAILABILITY |
| 18 AWG | 01P-S-TS • Red / White |
| 16 AWG | 01P-S-TS • Red / White |
| 14 AWG | 01P-S-TS • Red / White |
Additional information
| AWG | 14 awg, 16 awg, 18 awg |
|---|---|
| Brand | TMT Global |
| Colour | Red, White |
| Jacket Type | LSZH |
| Length | 305 m |
Download Spec.
Ordering Information
| Item Name | Item Code / SKU | Series | AWG / mm² | Jacket | Colour | Pack | QR Code |
|---|---|---|---|---|---|---|---|
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 18 awg | LSZH | Red | 305 m |  | |
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 18 awg | LSZH | White | 305 m | | |
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 16 awg | LSZH | Red | 305 m | | |
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 16 awg | LSZH | White | 305 m | | |
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 14 awg | LSZH | Red | 305 m | | |
| 1 Pair / 2 Core Standard Fire Telephone / EVC Cable | 01P-S-TS | 14 awg | LSZH | White | 305 m | |
